Transitions
Generate proportional transition drawings with inlet, outlet, length, offsets, connection type, liner, job details, and shop notes.
Private beta in development
DuctFormPro
Practical shop drawing tools for duct fittings, built for the way sheet metal work actually gets laid out.
Built from the shop floor
Faster duct fitting drawings without losing the details.
DuctFormPro is starting with duct transitions and expanding toward a full set of fitting tools. The goal is simple: enter field dimensions, generate a clean drawing, and give the shop the information where they expect to see it.
More fittings
Future tools are planned for common duct fittings so the workflow can grow into one practical shop drawing system.
Controlled access
The next release is being prepared as a private beta before the tool is opened to wider use.
Beta status
The public tool is temporarily closed.
The transition drawing app is being prepared for a protected DuctFormPro beta release. Access will be limited while the software, hosting, and future payment path are set up properly.
This website is the new home base for that work.
Request access
Interested in the beta?
Contact Danny for access while DuctFormPro is being prepared for its protected release.
